原帖由
松尾明 於 2015-5-21 04:14 PM 發表
順道一問, 坊間有種說法, 是出廠至戰地是防锈紅塗裝, 再在前線塗上土黃及綠色色塊而成三色迷彩, 不知是否這樣?
二戰納粹德軍戰車塗裝正式指引如下 :-
http://www.missing-lynx.com/panzer_facts.htm <------ 全文
摘要 :-
Start of the War
- two-tone scheme of Dunklegrau (dark grey RAL 7021) base coat, and Dunklebraun (dark brown RAL 7017).
June 1940
- only use Dunklegrau (dark grey RAL 7021) for the entire surface.
February 1943
- Dunklegelb nach Muster (dark yellow RAL 7028) as base coat
- Field units were issued Rotbraun (red brown RAL 8017) and Olivgruen (dark olive green RAL 6003) paste concentrate to create camouflage patterns suitable for local conditions.
August 1944
- Dunklegelb (dark yellow RAL 7028) as the base coat with Olivgruen (dark olive green RAL 6003) & Rotbraun (red brown RAL 8017) camouflages applied at the assembly plant.
(This has become known as the “ambush” camouflage scheme)
September 1944 (**松兄所提的)
- Panzers left the assembly plants with a base coat of primer Rot (dark red RLM 8012)
with only about half of the surface covered with patches of Rotbraun, Olivgruen, or Dunklegelb.
November 1944 (*** but not to go into full effect until June 1945)
- base coat of Dunkelgruen (dark green RAL 6003)
- camouflage pattern was to be created at the assembly plant by spraying on Rotbraun or Dunklegelb in sharp contours.
